Rimless AIO Aquarium Systems - Waterbox Aquariums

Select Option

Select Cabinet Color

Select Size

From $101.50

Original: $290.00

-65%

Rimless AIO Aquarium Systems - Waterbox Aquariums—

$290.00

$101.50

Select Option

Select Cabinet Color

Select Size

From $101.50

Original: $290.00

-65%

Rimless AIO Aquarium Systems - Waterbox Aquariums—

$290.00

$101.50

The Story

Description

The Display & Filtration

Newbie or Pro

The AIO was designed so you can keep more in your aquarium with less. Available from 10 through 65 gallons, the AIO delivers an aquatic environment for novice and professional aquarium keepers.

Adjustable Nozzle return allow for precise water agitation.

Ideal for novice and professional aquarium keepers

The unique filtration and baffle system forces the water to travel through the filter socks and then flow into chambers adequately sized for multiple types of filtration media.

AIO 20 & 25 include a perfectly matched return pump for optimal water turnover.

Filtration media is included to keep your water clear and polished.

The Cabinetry

Strength & Stability

Waterbox furniture is designed to elevate your living spaces with our first in class cabinetry and finishes. Available in white, black, or aspen.

Engineered to stand the test of time.

Constructed with aluminum framing to easily withstand the weight and humidity of your aquarium system.
Excluding AIO 20 Cube

Laminated wood panels skirt the aluminum framing for a sleek, modern look.

Adjustable Leveling Feet provide easy and effective way to ensure your aquarium is level, front to back and side-to-side.

FRESHWATER SERIES

Name: Rimless AIO Aquarium Systems - Waterbox Aquariums
Brand: Express
SKU: rimless-aio-aquarium-systems-waterbox-aquariums
Availability: InStock

AIO 10 CUBE FLED

Includes: Aquarium, Lighting (w/o controller), Filter Sock, Carbon Pellets, Ceramic Rings, Pump

AIO 15 PENINSULA FLED

Includes: Aquarium, Lighting, Filter Sock, Carbon Pellets, Ceramic Rings, Pump

AIO 35.2 PLUS Freshwater Edition

Introducing the Waterbox PLUS™ Edition aquarium systems - your hassle-free solution for setting up a new aquarium. Our meticulously designed complete packages take the guesswork out of the equation, providing you with expertly paired lighting, filtration, pumps, and supplies.

FLED - 17
FLED Support Extensions
SYNCRA SILENT 1.5
Mesh Lid System
SCUBA Preset Submersible Heater 150 Watts

AIO 50.3 PLUS Freshwater Edition

FLED - 34
FLED Support Extensions
SYNCRA SILENT 2.0
Mesh Lid System
SCUBA Preset Submersible Heater 200 Watts

AIO 65.4 PLUS Freshwater Edition

FLED - 46
FLED Support Extensions
SYNCRA SILENT 2.0
Mesh Lid System
SCUBA Preset Submersible Heater 200 Watts

SALTWATER SERIES

AIO 20 CUBE, AIO 25 PENINSULA

Includes: Aquarium, Filter Sock, Carbon Pellets, Ceramic Rings, Pump

AIO 20 CUBE PLUS Edition

Waterbox PLUS™ Edition packages simplify designing your system, providing you with expertly paired lighting, filtration, pumps, and supplies.

Prime 16HD Reef
Prime Flex Arm 12"
Comline® DOC Skimmer 9001
Mesh Lid System
Nero 3
SCUBA Preset Submersible Heater (100 Watts)

AIO 25 PENINSULA PLUS Edition

Prime 16HD Reef
Prime Flex Arm 18"
Comline® DOC Skimmer 9001
Mesh Lid System
Nero 3
SCUBA Preset Submersible Heater (100 Watts)

AIO 35.2 PLUS Edition

Prime 16HD Reef
Prime Flex Arm 12"
SYNCRA SILENT 1.5
Comline DOC Skimmer 9001
Mesh Lid System
Nero 5
SCUBA Preset Submersible Heater (150 Watts)

AIO 50.3 PLUS Edition

Prime 16HD Reef (2)
Prime Flex Arm 12" (2)
SYNCRA SILENT 2.0
Comline DOC Skimmer 9004
Mesh Lid System
Nero 5
SCUBA Preset Submersible Heater (200 Watts)

AIO 65.4 PLUS Edition

Prime 16HD Reef (2)
Prime Flex Arm 12" (2)
SYNCRA SILENT 2.0
Comline DOC Skimmer 9004
Mesh Lid System
Nero 5
SCUBA Preset Submersible Heater 300 Watts

Technical Specifications

PRODUCT MODEL		AIO 10 CUBE	AIO 15 PENINSULA	AIO 20 CUBE	AIO 25 PENINSULA
Aquarium	Dimensions (Length x Width x Height)	350 x 361 x 350mm	500 x 350 x 350mm	450 x 450 x 400mm	600 x 400 x 400mm
	Dimensions (Length x Width x Height)	13.8"×14.2"×13.8"	19.7"×13.8"×13.8"	17.7"×17.7"×15.7"	23.6"×15.7"×15.7"
	Glass Thickness	5mm (3/16")	5mm (3/16")	6mm (1/4")	6mm (1/4")
	Water Height	335mm/13.2"	335mm/13.2"	385mm/15.2"	385mm/15.2"
	Aquarium Volume	41 L/10.9 gals	57 L/15.2 gals	76 L/20.0 gals	90 L/23.7 gals
	Aquairum Weight	11.5 kg / 25.4 lb	14.0 kg / 30.9 lb	19.5 kg / 43.0 lb	21.5 kg / 47.4 lb
	Glass Material	Ultra-clear glass
	Transmittance	91%
	Media/Skimmer Chamber	125 x 80 x 350mm	125 x 80 x 345mm	200 x 80 x 400mm	173 x 80 x 394mm
	Media/Skimmer Chamber	4.9"×3.1"×13.8"	4.9"×3.1"×13.5"	7.9"×3.1"×15.7"	6.8"×3.1"×15.5"
	Filter Sock Chamber	80 x 80 x 350mm	80 x 80 x 350mm	80 x 80 x 400mm	80 x 80 x 400mm
	Filter Sock Chamber	3.1"×3.1"×13.8"	3.1"×3.1"×13.8"	3.1"×3.1"×15.7"	3.1"×3.1"×15.7"
	Pump Chamber	80 x 95 x 350mm	80 x 95 x 350mm	80 x 118 x 400mm	80 x 118 x 400mm
	Pump Chamber	3.1"×3.7"×13.8"	3.1"×3.7"×13.8"	3.1"×4.6"×15.7"	3.1"×4.6"×15.7"
	Directional Nozzle	1	1	1	1
	Return Hose	Φ16	Φ16	Φ16	Φ16
	EVA Mat	1	1	1	1
Accessories	Pump Flow	600L/h	1000L/h	1000L/h	1000L/h
	Directional Nozzle	✓	✓	✓	✓
	Return Hose	Φ16	Φ16	Φ16	Φ16
	225 Micron FELT Socks 2.75“	x 1	x 1	x 1	x 1
	Filtration Sponge	x 2	x 2	x 2	x 2
	Carbon Pellets	✓	✓	✓	✓
	Ceramic Rings	✓	✓	✓	✓
	EVA Mat	✓	✓	✓	✓
Mesh Lid (Optional)	Mesh Lid	✓	✓	✓	✓
Cabinet (Optional)	Cabinet Model	-	-	PB1818	-
	Dimensions	-	-	450 x 450 x 810mm	-
	Dimensions	-	-	17.7"×17.7"×31.9"	-
	Material	-	-	18mm Particle Board, PVC Laminated	-
	Color	-	-	WHT-White, BLK-Black, ASP-Aspen	-

PRODUCT MODEL		AIO 35.2	AIO 50.3	AIO 65.4
Aquarium	Dimensions (Length x Width x Height)	600 x 500 x 450mm	900 x 500 x 450mm	1200 x 500 x 450mm
	Dimensions (Length x Width x Height)	23.6"×19.7"×17.7"	35.4"×19.7"×17.7"	47.2"×19.7"×17.7"
	Glass Thickness	8mm (5/16")	10mm (2/5")	10mm (2/5")
	Water Height	435mm/17.1"	435mm/17.1"	435mm/17.1"
	Aquarium Volume	125 L/33 gals	186 L/49.1 gals	249 L/65.8 gals
	Aquarium Weight	34.0 kg / 75.0 lb	59.0 kg / 130.1 lb	65.0 kg / 143.3 lb
	Glass Material	Ultra-clear glass
	Transmittance	91%
	Filtration Chamber	600 x 120 x 450mm	900 x 120 x 450mm	1200 x 120 x 450mm
	Filtration Chamber	23.6"×4.7"×17.7"	35.4"×4.7"×17.7"	47.2"×4.7"×17.7"
	Filter Sock Chamber	81 x 120 x 450mm	81 x 120 x 450mm	161x120x450mm
	Filter Sock Chamber	3.2"×4.7"×17.7"	3.2"×4.7"×17.7"	6.3"×4.7"×17.7"
	Filter Media/Skimmer Chamber	101 x 120 x 450mm	154 x 120 x 450mm	150 x 120 x 450mm
	Filter Media/Skimmer Chamber	4"×4.7"×17.7"	6.1"×4.7"×17.7"	5.9"×4.7"×17.7"
	Pump Chamber	140 x 120 x 450mm	300 x 120 x 450mm	221 x 120 x 450mm
	Pump Chamber	5.5"×4.7"×17.7"	11.8"×4.7"×17.7"	8.7"×4.7"×17.7"
	Directional Nozzle	1	2	2
	Return Hose	Φ16	Φ24	Φ24
	EVA Mat	1	1	1
Filtration	Filter Socks	70mm/2.75" x 2	70mm/2.75" x 2	70mm/2.75" x 4
	Filtration Sponge	2	2	2
	Bio ball	24 pcs	24 pcs	48 pcs
Cabinet	Cabinet Model	ALU 2420	ALU 3620	ALU 4820
	Cabinet Dimensions	600 x 500 x 900mm	900 x 500 x 900mm	1,200 x 500 x 900mm
	Cabinet Dimensions	23.6" × 19.7" × 35.4"	35.4" × 19.7" × 35.4"	47.2" × 19.7" × 35.4"
	Cabinet Framework	Anti-corrosion Aluminum Alloy
	Door & Side Panels	18mm PVC Laminated Wood Particle Board
	Bottom Panels	10mm PVC Board
	Back Panels	6mm PVC Board
	Cabinet Color	WHT-White, BLK-Black, ASP-Aspen
	SUS304 Hinges
	Leveling Feet
